Kingda pump group
slurry Pump
Rubber Impeller
The rubber impeller, made from high-wear-resistant and corrosion-resistant rubber materials, is designed to withstand harsh operating conditions.
It significantly improves the durability and reliability of slurry pumps, making it the ideal solution for handling abrasive, high-concentration slurries.
- Exceptional Durability
- Perfect for Abrasive Slurries
- Enhanced Pump Reliability
- Cost-Efficient
Rubber Impeller
Overview
The rubber impeller is the core component of a horizontal slurry pump, responsible for generating the necessary pressure to effectively transport abrasive fluids and slurries. Due to the constant wear experienced by impellers during operation, selecting the right wear-resistant materials is critical to extending the impeller’s lifespan.
To meet the demands of slurry pumps handling high concentrations and highly abrasive materials, Kingda Rubber Impellers are made from a range of high-performance materials, including natural rubber, synthetic rubber, EPDM (ethylene propylene diene monomer), and nitrile rubber. These materials are specially engineered to withstand the harshest pumping environments, ensuring exceptional wear resistance and reliability even during prolonged operation, ultimately enhancing the overall performance and longevity of the pump.
Kingda’s rubber slurry pump impellers are available in the same dimensions as high-chrome alloy impellers. Additionally, we offer hybrid slurry pumps with metal impellers upon request, further enhancing the versatility and durability of the equipment. Whether it’s all-rubber parts or metal-rubber composite parts, Kingda provides custom solutions designed to meet the specific requirements of various operating conditions.
With these high-performance rubber components, Kingda ensures that slurry pumps operate efficiently and remain durable even in the harshest environments, helping industries tackle complex and demanding slurry handling challenges.
Types of Kingda Impeller
Kingda Pump Group offers three types of impellers: open, semi-open, and closed, designed to meet various operational requirements.
- Open Impeller: No shroud, ideal for handling slurries with large particles or high viscosity.
- Semi-Open Impeller: Features a shroud on one side, designed for medium viscosity and moderate solid content conditions.
- Closed Impeller: Equipped with shrouds on both sides, forming a complete flow path for maximum efficiency. It is perfect for handling low-viscosity slurries with minimal particle content, meeting the demands for high-efficiency pumping.
Whether dealing with high-viscosity, particle-rich slurries, or low-viscosity, particle-free media, Kingda impellers deliver optimal performance and efficiency.
Kingda Slurry Pump
Rubber Impeller Material
Excellent Wear Resistance
Rubber impellers offer superior wear resistance, effectively extending the pump’s lifespan and reducing the cost of frequent impeller replacements.
Corrosion Resistance
They have strong resistance to corrosive substances like acids and alkalis, making them ideal for harsh operating environments.
Improved Efficiency
The flexibility of rubber impellers enhances the overall efficiency of the pump, enabling it to better handle complex working conditions.
Lightweight
Compared to metal impellers, rubber impellers are lighter, reducing equipment load and lowering energy consumption.
Easy Maintenance
Rubber impellers are less prone to damage and are easier to replace and maintain, which reduces maintenance costs.
| Kingda Coad | Material | Description | Chemical Resistance |
|---|---|---|---|
| KJZ-01 | Natural Rubber | Suitable for ordinary chemical media with a weight concentration ≤ 65%, solid particle size generally ranging from 80 to 200 mesh, and a small percentage of particles up to 3mm. The pH range is from 2 to 14. |
Sulfuric Acid :≤20% at ≤65°C Phosphoric Acid : ≤60% at ≤65°C Nitric Acid : ≤1% at room temperature Hydrofluoric Acid : ≤5% at room temperature Sodium Hydroxide :≤20% at ≤65°C |
| KJZ-02 | |||
| KJZ-03 | |||
| KJ21 | Butyl Rubber | Suitable for solutions with higher temperatures and excellent resistance to water-based solutions; unaffected by strong acids and alkalis. However, concentrated oxidizing acids and nitric acid may cause material degradation, and it will swell in oxidizing hydrocarbon solutions. |
Sulfuric Acid :≤50% at ≤65°C Phosphoric Acid :≤85% at ≤85°C Hydrochloric Acid :≤20% at ≤65°C Nitric Acid :≤10% at ≤40°C Sodium Hydroxide :concentrated at ≤85°C |
| KJ22 | Hypalon Rubber | Resistant to both organic and inorganic chemicals, primarily used in acidic environments. It also resists vegetable oils and mineral oils, but is not recommended for use with chlorinated solvents. |
Sulfuric Acid :≤80% at ≤65°C Phosphoric Acid :≤85% at ≤95°C Hydrochloric Acid :≤37% at ≤50°C Nitric Acid :≤30% at room temperature Sodium Hydroxide :≤70% at ≤110°C |
| Insp Item | Unit | Test Conditions | Benchmark Value | Measured value |
|---|---|---|---|---|
| Hardness | Shore A |
140℃ x 10min Dumbbell cutter Dumbbell L-shaped Rip cutter right angle |
49±4 | 48 |
| Tensile Strength | Mpa | ≥20 | 27.4 | |
| Breaking Elongation | % | ≥500 | 837.5 | |
| 300% Stretching Strength | Mpa | ≥4 | 7.11 | |
| Tear Resistent | KN/m | 780 | ||
| Specific Gravity | g/cm³ | 1.09 | ||
| Mooney | moony | ML1+4@100℃ | 59.1 | |
| Scorch | m:s | t5@140℃ | 6‘47“ | |
| Abrasion Resistance | cm³/1.61km | 0.0736 |
Kingda Rubber Physical Properties Test Report
Quality Management
Our rigorous quality control system ensures excellence at every step—from selecting and analyzing raw materials to precision machining and performance testing of pump parts. We adhere to the highest inspection standards to guarantee that each component arrives to our customers in perfect condition, earning their trust with consistent and reliable quality.
Slurry Pump Parts
OEM & ODM services
With over 70 years of experience, we are a leading manufacturer of slurry pumps, providing high-quality impellers, spare parts, and wear components to some of the world’s most renowned pump manufacturers. Our parts are 100% interchangeable with those of leading pump brands, ensuring seamless integration and perfect compatibility.
Equipped with a state-of-the-art materials and product lab, we focus on enhancing the durability of our parts through innovation and technology, extending their service life. Our full production capabilities cover every stage, from model making and casting to heat treatment, machining, welding, rubber lining, assembly, and testing, ensuring the highest standards of quality at every step.
Supported by a dedicated team of professional maintenance engineers, we offer 24/7 online support for quick response and efficient solutions, ensuring minimal downtime and maximum reliability. Our technical depth and commitment to excellence have positioned us at the forefront of the slurry pump industry, delivering exceptional products and solutions to our customers worldwide.
Application
Slurry pumps transport mud, sand, lime slurry, ash and other substances in the fields of mining, metallurgy, coal, electric power, chemical industry and environmental protection, and play an important role in various technological processes in many industries. Efficiently and reliably convey and process high-concentration, high-density, high-abrasive slurry.
Processes
Cement Production | Dredging Operations | Flue Gas Desulfurization | Backfilling Pumping | Concentrate Slurry Pumping | Cyclone Feed Pumping | Tailings Handling | Flotation Slurry | Pumping | Hydraulic Transport | Mill Discharge Pumping | Multistage Pumping | Process | Material Pumping | Concentrate Material Pumping | Sugar Cane Refining | Tunnel Construction
